Power parameters
Input power: AC100-240V
Power frequency: 50/60Hz
Power: 280W
Luminaire parameters
Waterproof coefficient: IP20
Heat dissipation mode: air cooling
Maximum ambient temperature: 45°C
Housing color: black
Lamp bead specifications
Lamp bead specification: 250W MSD bulb
Color temperature of lamp beads: 8000K
Average life of lamp beads: 2,000 hours
Control system
Number of DMX control channels: 16CH
DMX connector: 3 Pin XLR input and output
Power connector: gun control tail input
Operating mode: master-slave/auto/voice/DMX
Horizontal: 540º, 16-bit precision scanning
Vertical: 270º, 16-bit precision scanning
Color wheel: 14 fixed colors + white
Gobo graphy: 8 fixed patterns + 5 glass patterns + white circles
Prism: 48 bee prism with rotation
Full-color TFT screen with 5 buttons
Color effects
Color: 14 fixed colors + white
Luminous angle: 2°
Strobe: 1-25Hz
Linear dimming: 0-100%
Illumination: 48300 lux at 10 meters of full brightness
Size dimensions (LxWxH): 34 x 32x50cm
NET WEIGHT: 14.6KG
