Technical Specifications
Voltage : AC100-240V 50/60Hz
Power : 580 W
Light source : high brightness light source module
Light source life : 20,000 hours
Optical Angle : 5°-55°
Level : 540 degrees +16bit fine tuning
Vertical : 270 degrees +16bit fine-tuning
Channels : 26 standard DMX channels with RDM function
CTO : Independent rising and cooling color film
Color : 8 colors + white light. Color Half color function
Rotation pattern : 7 rotation pattern pieces + white light, pattern water
effect, pattern shaking effect, can achieve two-way water
Atomization : with a atomizing mirror to achieve dyeing effect
Cutting disc : a group of 8 cutting blades composed of controllable light
spot cutting Angle system, through the precise control of cutting light, can
create any direction of triangular, diamond, rectangular and other shapes
of light spots
Dimming : 0-25HZ/ SEC, electronic linear dimming, high-speed stroboscopic, a variety of stroboscopic effects
Focus : Linear focus function
2.8-inch LCD LCD touch screen, Chinese and English languages can be
switched at will, the font can be automatically 180 degrees reverse display
Control signal : international standard DMX512. With RDM function, online software upgrade, dial the address code
Cooling method : Use axial fan to strengthen cooling
Safety device : with electronic temperature control overheat protection, overheat system failure electronic temperature control automatic power off protection
Appearance material : high temperature resistant plastic
Working environment : -20 degrees, 40 degrees
Protection level : IP20
Product size : 380×270×650mm
N.W : 22.5kg
