Channels Mode: 44/45/50CH
Light Source
Lamp: 500W White LED Engine
Life time:20000 hours
Light Source Luminous Flux:17687lm
Illuminance at 10m:9900lux,minimum spot 1.35m
Optical System
Beam angel : 8~53°
Dimmer : 0-100% linear adjustment
Iris: Disphragm adjustable
Gobo Wheels
Fixed gobo : 9 gobo + white.
Rotation gobo: 8 gobo+ white,changeable
Color Wheels
6 fix colors+white+CRI+CMY+CTO.
Prism System
Prism: 3 facet prism ,Frost function
Framing System
Cut: 4 plates.Aftercut,the pattern canrotation 180°
Position lock system: Magnetism positionlock system
Control & Screen
Display: 2.8 inch screen display, canreverse 180°
Connector can set dmx address with power and upgrade the software.
Electrical Info
Power: AC180-240V,50/60Hz
Total power: 650W
PAN & TILT
Pan : 540°; 8Bit/16Bit
Tilt : 270°; 8Bit/16Bit
Size & Weight
Product size: 375x255x620mm
Carton box: 690x325x440 mm
N.W: 22.5KG
G.W:25KG(carton box)
