Specification:
Input voltage: AC100-240V 50/60Hz
Power consumption: 900W
IP rating: IP20
Cooling method: fan cooling
Max ambient temp: 45℃
Case color: black
LED: 700W white LED module
Color Temp:8000K
CRI:>80
Average lifespan: 20,000 hours
Control
DMX channel: 36CH
DMX connector: 3Pin XLR input/output
Power connector: PowerCon input
Control mode: DMX/master-slave/auto/sound/RDM
Pan: 540º16bits, Tilt: 270º16bits
Precise and fast Pan/Tilt movements
Motorized focus, frost, zoom, iris, split color 3-phase motor for Pan/Tilt, automatic position correction
Static gobo wheel: 8gobos plus open with gobo shaking function
Rotating gobo wheel: 7 replaceable gobos plus open with
gobo shaking function
Static color wheel: 6colors plus open,and split color effect
Smooth CMY+CTO color mixing system
Prism 1: 3-facet rotating
Aperture: 5-100% smooth adjustment
Full color LCD touch display with 4 buttons
With RMD function and software upload via DMX cable
Cutting disc: a set of controllable light spot cutting angle system composed of 4 corner cutting pieces, the entire cutting angle system can rotate by 90º, and through precise control of the cutting lens, can create any direction of triangle, rhombus, rectangle and other shapes of light spots
Color effect
Color: 6 colors+open, split color,CMY+CTO color mixing
Beam angle: 4-49°
Dimming: 0-100% linear
Strobe: 0-25Hz, random strobe and pulse strobe
Lux: 110,000Lux @ 5m & 4°(spot Ø 39mm),
Dimension
Product dimension: 50*34*80 cm (LxWxH)
N.W: 40KGS
