Led Source
Light Source : 12x40W 4inl RGBW Original Orsam LED
Zoom Range : 2.8°- 55 °
Dimming : 0- 100° smooth dimming
CCT : 2500-8000k ( adjustable )
Strobe : 0-20Hz
Luminous : 8212lm / 10m 2.8°
Control
DMX Channel : 11CH / 17CH / 18CH / 58CH
Control Mode : DMX512, Master-Slave , Sound Slave
Pan/Tilt
Pan/Tilt:540°/270° // Pan/Tilt Resolution:16bit
Construction
Data In/Out : 3-pin&5-pin XLP
Power in/Out : Power Con in / out
Protection Rating: IP20
POWER
Power Voltage : AC100-240V,50/60Hz
Power Consumption : 600W
Working temperature : -20 ~ 40°
DIMENSIONS
Dimensions : 470x400x270 mm
