Leading Performance:
· Complies with National Standard GB/T 13582-92, GB/T14218-93, GB/T15734-1995, reliable quality,
Passing the international CE certification.
· 4KW/channel for 12 channels.
· Intelligent control panel, most convenient humanistic operation interface.
· Intelligent jumper: dimmers can be configured to any DMX dimmer.
· Field lighting and beam-focusing: 6/12 channels digital lighting
(the one whose proportion to the brightness value of DMX signal is bigger takes precedence),
sets the brightness value of any dimmer freely, centralized control which can turn on/off self-lighting conveniently.
· A/B independent DMX signal input which can be set in modes, such as singleness
(A or B)/ mix (the bigger one takes
precedence)/back up (A takes precedence and switches automatically) and so on.
· Field backup: records DMX signal field, self programming field, deletes or runs field.
· Lighting with programme control: adjusts the brightness of every channel through,lighting buttons of own in a
real time way, adjusts the speed through“↑”, “↓”.
· System status reporting: observes the temperature of triacs and dimmer, network voltage input, dimmer
voltage and current
output via algorism, observes the lighting brightness (DMX signal value) by means of algorism, hex,
lighting list and so on, observes output circuit status as OK/open/short (selected mating).
· Over temperature reporting and protection: reports when the rack temperature exceeds 80℃ or the dimmer
temperature
exceeds 60℃(freely changes the setting value) : protects itself automatically when the rack temperature
exceeds 105℃ or the dimmer temperature exceeds 80℃(turns on /off the function freely); output overflowing
(short) protect which avoids dimmer burning to maximum.
· Lighting curve selecting: presets 10 lighting curves for customers to choose.
· Lighting range: 0-100%
· Fan automatic switching: Turns on when the temperature exceeds 50℃(turns off the function freely).
· A, B, C, D output versions.
Technical Parameters:
Power supply：3 phases 4 wires, biphase or monophase power supply, with ground wire, monophase at
220 Volt±10%, 50Hz
Control signal：DMX-512
Rated power：4KW/channel
Installation size：530×435×180(mm)
Weight：13.4kg
