Up to 4096 DMX channels. With 6 individual optical isolated DMX outputs and 2 Net-work interfaces.
-
Maximum 400 Units for patching all kinds of Fixtures.
-
Fixtures within 80 channels are available.
-
10.4"TFL-LCD touch screen displays in Chinese/English. Offer a VGA interface for external monitor connection to display more edited information.
-
Up to 720 Playbacks, controlled by 24 Playback faders × 30 pages. 4 Optical Encoders.
-
Up to 400 Groups.
-
Up to 400 Presets.
-
Shortcut area provides a quick way for selecting Fixtures, Groups, Presets or Shape Effects.
-
Color-mix system provides a color palette for users to control fixtures with RGB or CMY channels conveniently.
-
Shape Generator provides various effects, such as Circle,
-
Provide over 8000 System Libraries. Enable users to edit System Library or create Custom Library.
-
Support multiple DMX network protocols. DMX 512 signal can be transmitted over network.
-
Freely download Upgrade Version and System Library.
-
An internal electronic disk allows user to backup datum.
-
USB interface allows users to backup shows in external disk.
-
Music trigger function.
-
Blackout function.
-
Provide MIDI in and out interfaces to connect and work with other consoles.
-
Option: 12V auxiliary light.
-
Power supply: AC100-240V, 50-60Hz.
-
Size: 650mm × 490mm × 130mm.
-
Net weight: 13Kg approx.
